Fitment Information

• Audi RS4 AWD (2001, 2002, 2003, 2004, 2005, 2006)
• Audi RS4 4.2 FSI Quattro, AWD (2007, 2008)
• Audi RS4 Cabrio AWD (2008)

Specs & Features

• Bolt Pattern: 5/112
• Center Bore: 57.1
• Bolt or Stud: Bolt
• Thread Type: 14x1.5
• Sold as a pair

• Series Option
  • DR Series – 3mm to 23mm widths, requires longer wheel bolts (ordered separately)
  • DRA Series – 20mm to 45mm widths, bolts directly to hub with included special wheel bolts, provides new threaded holes for existing wheel bolts

Product Description

There’s a reason high-end performance cars sit the way they do. The wheels are pushed perfectly toward the edge of the fender, giving the car a wider, more planted look that instantly makes everything feel more aggressive. H&R TRAK+ Wheel Spacers bring that same fitment philosophy to your setup without cutting corners. Whether you’re trying to eliminate that sunken factory wheel look, clear suspension components, or dial in the perfect stance after lowering your vehicle, these spacers make a huge visual difference the second they go on.

But this isn’t just about looks. H&R builds these spacers using a proprietary alloy specifically engineered for strength while keeping weight down, and the hubcentric design keeps everything centered properly just like the factory hub. No cheap universal spacer feel, no sketchy fitment—just a solid, confidence-inspiring setup designed for real performance use. From mild flush fitment to full wide-body style aggression, TRAK+ spacers are one of the simplest upgrades that completely changes the personality of the vehicle.

Important

5mm / 5mm Black / 8mm / 8mm Black / 15mm / 15mm Black / 20mm / 20mm Black DR Wheel Spacer:

• All DR-Systems require longer wheel bolts. These must be ordered separately. H&R Wheel Spacer Bolts are listed here. When ordering wheel bolts, please follow these guidelines:

a) If possible, name the brand of wheel.

b) New bolts must be longer than the original bolts by the width of the wheel spacer used.

c) The bolt head must be identical to the existing bolt:
Taper 60° End digit 01
Round head for M12/d24 mm, for M14/d28 mm End digit 02
Round head for M12/d26 mm (e.g. OE VAG-wheels) End digit 03
Flat head for Porsche original wheels M14 x 1.5 End digit 06

d) Safety guidelines
(Minimum number of turns for wheel bolts / nuts):
M12 x 1.25 = 8.0 turns = approx. 10 mm of load bearing shaft length
M12 x 1.50 = 6.5 turns = approx. 10 mm of load bearing shaft length
M12 x 1.75 = 6.5 turns = approx. 12 mm of load bearing shaft length
M14 x 1.25 = 9.0 turns = approx. 12mm of load bearing shaft length
M14 x 1.50 = 7.5 turns = approx. 12 mm of load bearing shaft length
1/2" UNF = 8.0 turns = approx. 11 mm of load bearing shaft length

e) Please ensure that the wheel bolts do not damage any part of the brake system (ABS sensors, etc.). Turn the wheel by hand and check clearance on the inside of the hub. The wheel should rotate freely. (Maximum tolerance for some vehicles is only 2mm -- i.e. Rear Axle Mercedes).

5mm / 5mm Black / 8mm / 8mm Black

• These are hub-centric flat disc type spacers which require the factory hub to center the wheels. Please measure the vehicle hub to verify sufficient height will remain to center the wheel after spacer installation.
